General Specs |
| Product Weight (lbs.) | 17.19 |
| Depth (in.) | 13 |
| Width (in.) | 17 |
| Height (in.) | 6.25 |
| Channels | 7.2 |
| Bluetooth | Yes |
| Remote Control Type | Wireless Remote |
| Bluetooth Capable | Yes |
Connections |
| HDMI Inputs: | 4 |
| USB Port: | 1 |
| Composite Video Inputs: | 2 |
| Analog Audio(RCA) Input: | 4 |
| Coaxial Digital Audio Inputs: | 1 |
| Composite Video Outputs: | 1 |
| HDMI Outputs: | 1 |
| Headset Jack: | Yes |
| Optical Digital(Fiber Optic) Audio Inputs: | 1 |
| Preamp Outputs: | 2 |
Features |
| On Screen Display: | GUI |
| Tuning Presets: | Yes |
| Sleep Timer: | Yes |
| 3D Passthrough: | Yes |
| AM/FM Tuner Built-In: | Yes, FM Only |
Other |
| Speaker A/B Switching: | Yes |
Amplifier |
| Number Of Amp. Channels | 7ch |
| Audio Enhancer | Yes |
| Bi-Amp | Yes |
| HD-D.C.S. (Digital Cinema Sound) | Yes |
| Night Mode | Yes |
| Portable Audio Enhancer | Yes |
| Sound Field Program (2CH/Multi) | Yes |
| Sound Field Program (A.F.D.) | Yes |
| Sound Field Program (Headphone) | Yes |
Video Features |
| HDR (High Dynamic Range) | Yes |
| Audio Return Channel | Yes |
| HDMI® Pass Through | Yes |
| 3D Over HDMI | Yes |
| 4K 60P 4:4:4 Support | Yes |
| A/V Sync | Yes (Fixed) |
| Bravia® Sync (CEC Control) | Yes (One-Touch Play, System Audio Control, System Power Off) |
| 1089P/24P | Yes |
| Deep Color | Yes |
| Triluminos | Yes |
Auto Speaker Calibration |
| DCAC (Digital Cinema Auto Calibration) | Yes |
Tuner Features |
| Preset Channel (FM/AM) | (-/-/30/30) |
| RDS | Yes |
Interface |
| Input And Output Terminals | HDMI Video In/Out (4);Composite Video Input (2);Composite Monitor Out (1);Opt Audio Input (1);Coax. Audio Input (1);Analog Audio Input (4);Subwoofer Output Pre out (2);Headphone Output (Gold);USB (1 Front); Bluetooth®(3.0) |
Decoding Format |
| DTS HD/DolbyTruHD/Dolby Digital+ | Yes/Yes/Yes |
| LPCM (2 CH/5.1 CH/7.1 CH)Through HDMI | Yes (192kHz/24bit/Up to 7.1ch) |
| Dolby Digital/DTS | Yes/Yes |
| Dolby Digital Ex | Yes |
| DTS-ES (MATRIX6.1/DISCRETE6.1) | Yes |
| DTS 96/24 | Yes |
| Dolby Prologic | Yes |
| Dolby Prologic II | Yes |
| Dolby Prologic IIX | Yes |
| Dolby Dual Mono | Yes |
| DSD | Yes |
| 96K/24 Bit PCM | Yes |
Network Connectivity |
| Music Decoding Format For Network Client | [MP3].mp3, [AAC].m4a [WMA9 Standard].wma, [LPCM].wav |
Eco and Energy Saving |
| Power Consumption (Standby Mode) | 0.3 W |
| Power Consumption (Networked Standby Mode) – Terminals | 0.5 W (Bluetooth®) |
General Features |
| Auto Standby | Yes |
| GUI (Graphical User Interface) | Yes (Only through HDMI) |
Size and Weight |
| Dimensions (W x H x D IN) | 19.53 x 8.31 x 15.59 in |
| Weight (Lb.) | 17.20 lb |
